The JF-XX200 Hybrid Multi-rotor UAV adopts a six-axis and six-propeller configuration as well as an environment-resistant design. It is equipped with fully automatic take-off and landing functions, and features extremely high flexibility, military-grade stability, large payload capacity and high reliability. It is widely used in scenario-level fields such as emergency communications, emergency rescue, high-intensity lighting, reconnaissance and search, material delivery, geographical mapping, power/pipeline inspection, and land resource survey.

Technical Parameters
Wheelbase: 4000 mm
Unfolded Dimensions: 4 × 4 × 1.5 m
Maximum Payload Capacity: 200 kg
Maximum Take-off Weight: 500 kg
Communication Range: 20 km
Maximum Take-off Altitude: 3000 m
Maximum Flight Speed: 10 m/s
Wind Resistance Class: Level 6
Deployment Time: 2 min
Endurance: 60 min

Detailed technical parameters: Please refer to CC_junfemg@163.com Request.
