In the face of the intelligent wave in the automotive industry, Dongfeng Mhero Technology and Huawei have joined forces to integrate Huawei's leading "full-stack" technologies into Mhero's rugged DNA, creating a harmonious "symphony" of intelligent off-roading. The JF-M817 achieves an intelligent revolution in driving experience through Huawei's world-leading intelligent automotive solutions, including Qiankun Intelligent Driving HUAWEI ADS 4, HarmonyOS Cockpit 5, Qiankun Vehicle Cloud, and Qiankun Vehicle Control, making driving easier, safer, and more enjoyable.

information	we.jfqcgs.com
厂商	Manufacturers	猛士科技 Mhero
级别	level	大型 SUV Large SUV
能源类型	Type of energy	插电式混合动力 Plug-in-hybird
环保标准	Environmental standards	国 VI National VI
上市时间	Availability	-
WLTC 纯电续航里程 (km)	WLTC electric range (km)	110
CLTC 纯电续航里程 (km)	CLTC electric range (km)	140
电池快充时间 (小时)	Battery Fast Charging Time (Hours)	0.25
电池慢充时间 (小时)	Slow Battery Charging Time (Hours)	4.3
电池快充电量范围 (%)	Battery Fast Charge Range (%)	30-80
电池慢充电量范围 (%)	Battery Slow Charge Range (%)	20-100
最大功率 (kW)	Maximum Power (kW)	505
最大扭矩 (N・m)	Maximum torque (N・m)	848
变速箱	Gearbox	-
车身结构	Body structure	5 门 5 座 SUV 5-door-5-seat SUV
发动机	motor	1.5T 197 HP L4
电动机 (Ps)	Electric Motor (PS)	551
长宽高 (mm)	Length, Width & Height (mm)	5.1002E+11
官方 0-100km/h 加速 (s)	Official 0-100km/h acceleration (s)	5.2
最高车速 (km/h)	Maximum speed (km/h)	180
整车质保	Vehicle warranty	-
整备质量 (kg)	Curb weight (kg)	2885
最大满载质量 (kg)	Maximum Mass at Full Load (kg)	3395
准拖挂车总质量 (kg)	Gross mass of quasi-trailer (kg)	2500
长度 (mm)	Length (mm)	5100
宽度 (mm)	Width (mm)	1998
高度 (mm)	Height (mm)	1919
轴距 (mm)	Wheelbase (mm)	3005
前轮距 (mm)	Front track (mm)	1720
后轮距 (mm)	Rear track (mm)	1717
最小离地间隙 (mm)	Minimum Ground Clearance (mm)	237
接近角 (°)	Angle of approach (°)	31
离去角 (°)	Departure Angle (°)	31
纵向通过角 (°)	Longitudinal passing angle (°)	20
最大爬坡度 (%)	Maximum Gradeability (%)	100
最小转弯半径 (m)	Minimum turning radius (m)	6.2
最大涉水深度 (mm)	Maximum wading depth (mm)	820
车身结构	Body structure	SUV
车门开启方式	How the doors open	平开门 sing door
车门数 (个)	Number of Doors (pcs)	5
座位数 (个)	Number of seats (pcs)	5
油箱容积 (L)	Fuel Tank Volume (L)	54
后备厢容积 (L)	Trunk volume (L)	828-2112
风阻系数 (Cd)	Drag coefficient (Cd)	-
发动机型号	Engine model	DFMC15TE6
排量 (mL)	Displacement (mL)	1497
排量 (L)	Displacement (L)	1.5
进气形式	Air intake form	涡轮增压 turbo
气缸排列形式	Cylinder arrangement	L
气缸数 (个)	Number of cylinders (pcs)	4
每缸气门数 (个)	Valves per cylinder (pcs)	4
配气机构	Valve mechanism	DOHC
最大马力 (Ps)	Maximum Horsepower (Ps)	197
最大功率 (kW)	Maximum Power (kW)	145
最大功率转速 (rpm)	Maximum power speed (rpm)	-
最大扭矩 (N・m)	Maximum torque (N・m)	-
最大扭矩转速 (rpm)	Maximum Torque Speed (rpm)	-
最大净功率 (kW)	Maximum Net Power (kW)	137
能源类型	Type of energy	插电式混合动力 Plug-in-hybird
燃油标号	Fuel designation	95 号
供油方式	Fuel supply method	直喷 Direct injection
缸盖材料	Cylinder head material	铝合金 Aluminum alloy
缸体材料	Cylinder block material	铝合金 Aluminum alloy
环保标准	Environmental standards	国 VI National VI
电机类型	Motor type	永磁 / 同步 Permanent magnet / synchronization
电动机总功率 (kW)	Total motor power (kW)	405
电动机总马力 (Ps)	Total motor horsepower (ps)	551
前电动机最大功率 (kW)	Front motor max power (kW)	200
后电动机最大功率 (kW)	Maximum power of rear motor (kW)	205
系统综合功率 (kW)	Combined system power (kW)	505
系统综合功率 (Ps)	Combined System Power (PS)	687
系统综合扭矩 (N・m)	Combined system torque (N・m)	848
驱动电机数	Number of drive motors	双电机 dual motor
电机布局	Motor layout	前置 + 后置 front rear
电池类型	Battery type	磷酸铁锂电池 Lithium iron phosphate battery
电芯品牌	Cell brand	时代一汽 Times FAW
电池冷却方式	Battery cooling method	液冷 liquid cooling
WLTC 纯电续航里程 (km)	WLTC electric range (km)	110
CLTC 纯电续航里程 (km)	CLTC electric range (km)	140
CLTC 综合续航 (km)	CLTC combined range (km)	1300
电池能量 (kWh)	Battery Energy (kWh)	31.7
百公里耗电量 (kWh/100km)	Power consumption per 100km (kWh/100km)	24.8
快充功能	Fast charging function	支持 support
电池快充时间 (小时)	Battery Fast Charging Time (Hours)	0.25
电池慢充时间 (小时)	Slow Battery Charging Time (Hours)	4.3
电池快充电量范围 (%)	Battery Fast Charge Range (%)	30-80
电池慢充电量范围 (%)	Battery Slow Charge Range (%)	20-100
简称	abbreviation	-
挡位个数	Number of gears	-
变速箱类型	Gearbox type	-
驱动方式	Drive mode	前置四驱 Front-wheel drive (4WD)
四驱形式	Four-wheel drive form	电动四驱 Electric four-wheel drive
前悬架类型	Front suspension type	双叉臂式独立悬架 Double wishbone independent suspension
后悬架类型	Rear suspension type	双叉臂式独立悬架 Double wishbone independent suspension
助力类型	Assist type	电动助力 Electric power steering
车体结构	Body structure	非承载式 Body-on-frame (non-load-bearing type)
前制动器类型	Front brake type	通风盘式 Ventilated disc brakes
后制动器类型	Rear brake type	通风盘式 Ventilated disc brakes
驻车制动类型	Type of parking brake	电子驻车 Electronic parking brake (EPB)
前轮胎规格	Front tire specifications	275/60 R20
后轮胎规格	Rear tire specifications	275/60 R20
备胎规格	Spare tire specifications	全尺寸
外观颜色	Exterior color	秦岭绿、格宗黑、昆仑白、鸣沙黄、茶卡蓝、玉龙银 green, black,white,yellow,blue,silver
内饰颜色	Interior color	青山黛、丹霞棕、迎松墨 black,brown,dark black
通信系统	Communication system	俊风将以专用车改制的方式出口燃油车,专用车将加装部分专用设备,车辆改制成本由俊风公司承担，详情请见具体合同。  Junfeng will export the fuel powered vehicle through the transformation of a specialized vehicle. Specialized vehicles will be equipped with some specialized equipment. The cost of vehicle restructuring will be borne by Junfeng Company.For details please see the contract.
other	Secondary parameters	The parts and components are constantly updated in production. The above parameters are only for reference and are mainly based on actual vehicles. The core parameters and configuration remain unchanged.
OEM customization		Wuhan Junfeng Automobile Co., Ltd.
FCA Shanghai Port
Quote description	The quotation in Renminbi is converted at the USD exchange rate of the day (6.5:1). When the exchange rate fluctuates by 5%, the settlement price will be readjusted. 2. The AFRI after-sales warranty, crisis, and recall fees are not charged in the settlement price.3.This quotation is a price within 50 vehicles. After more than 30 vehicles, a very surprising commercial discount will be given according to the quantity; different prices will be implemented in stages according to different quantities.
